LumiCure Light
1 / 5
Scope of Application: VU coating, hardware, screen printing, glass, plastic, surface finishing, UV inks, coating experiments, etc. With higher UV energy, the coating has stronger penetration capability. Our UV LAMP features high UV frequency, fitting almost all UV INK and UV glue. The UV Lamp useful operation lifetime is guaranteed for 1000-1200 hours. Features TM speed adjustment, with a conveyor belt running speed range of 0-10M/min.
| Parameter | Specification |
|---|---|
| Model | NT-1500A |
| Belt size | 1500*500mm |
| Power | 3.5KW |
| Voltage | 220V/380V |
| Working area | 700mm |
| Height of entrance | 100-200mm |
| Height of lamp | 100-200mm (adjustable) |
| Feeding area | 400mm |
1. All goods shipped by express require the buyer to pay import tax duties.
2. When the goods arrive, the buyer must check if the packaging or the machine is damaged. If any damage is found, the buyer should refuse to sign for the delivery and immediately file a complaint with the local express courier. The buyer can report the damage situation to us within 24 hours, and we will assist in resolving the issue. Please note that we bear no responsibility for transport damage if this process is not followed.
What is the primary application of this UV curing machine?
This machine is widely used for curing VU coatings, hardware finishes, screen printing processes, glass, plastic treatments, surface finishing, and drying UV inks. It has strong penetration capability thanks to high-frequency UV energy.
Is the height of the UV lamp adjustable?
Yes. The height of the UV lamp can be manually adjusted from 100mm to 200mm, allowing you to accommodate products of varying thicknesses and profiles.
What is the lifespan of the UV lamp?
The UV lamp has a guaranteed service life of approximately 1,000 to 1,200 operating hours under standard running conditions.
How fast can the conveyor belt run?
The conveyor belt features stepless speed adjustments, allowing for smooth operation and conveying speeds ranging from 0 to 10 meters per minute.
What built-in safety protection systems are included?
The equipment is built with advanced safety controls, including an abnormal lamp shutdown protection device, over-voltage protection, over-current protection, equipment overload protection, and an integrated fault alarm system.
What should I do if my machine arrives damaged during transit?
Please inspect the shipment immediately upon delivery. If damage is found, do not sign for the package and report the issue to the local shipping courier right away. Inform us with pictures of the package and machinery damage within 24 hours, and we will support you in resolving the claim.
