LumiCure Light
1 / 5
Scope of Application: VU coating, hardware, screen printing, glass, plastic, surface finishing, UV inks, coating experiments, etc. With higher UV energy, the coating has stronger penetration capability.
| Parameter Item | Specification Details |
|---|---|
| Model | NT-1500A |
| Belt size | 1500*500mm |
| Power | 3.5KW |
| Voltage | 220V/380V |
| Working area | 700mm |
| Height of entrance | 100-200mm |
| Height of lamp | 100-200mm (adjustable) |
| Feeding area | 400mm |
Adjustable height 100-200mm, manual adjustments.
Used for measuring AC voltage accurately.
High quality, wear-resistant conveying belt.
Forced wind exhauster set to clear out harmful gases.
This curing machine is widely applicable for VU coatings, hardware, screen printing, glass processing, plastic surfaces finishing, UV ink projects, and various laboratory coating experiments.
The built-in UV lamp features a reliable working lifespan of approximately 1,000 to 1,200 hours under standard operation conditions.
Yes, the conveyor belt has a stepless speed regulation mechanism allowing smooth adjustments between 0 to 10 meters per minute.
Yes, each UV lamp's height is manually adjustable within a range of 100mm to 200mm to suit different curing thicknesses and needs.
The system includes over-voltage and over-current protection, fault alarm indicators, equipment overload protection, abnormal lamp warnings, and a forced wind combination exhauster for clearing out gases.
Do not sign the receipt if you find the package or machine damaged. Complain immediately to the courier agency and report the damage details to us within 24 hours so we can support your claim and resolution.
